Name: SD12D 1 Ton mini excavator
SKU: 536
Availability: InStock

SD12D 1 Ton mini excavator

PARAMETER

No	Item	Data
1	Power	8.6 kw
2	Bucket cap	0.028m3
3	Operating weight	1000Kg
4	Max. Digging Height	2650mm
5	Max Digging Depth	1650mm
6	Overall Length	2770mm
7	Arm Length	800mm
8	Boom Length	1490mm

SD12D 1 Ton Mini Excavator

Compact, powerful, and highly efficient — the SD12D 1 Ton Mini Excavator is designed to tackle tight-space jobs with ease. Whether you’re working on landscaping projects, small-scale construction, or trenching tasks, this machine delivers reliable performance and precision every time.

Key Features:

Powerful Engine: Equipped with an 8.6 kW engine, the SD12D ensures consistent output and fuel efficiency for extended work sessions.
Compact Design: With an overall length of just 2770mm, this mini excavator fits into tight spots without sacrificing performance.
Efficient Digging Capabilities:
- Maximum Digging Height: 2650mm
- Maximum Digging Depth: 1650mm
- Bucket Capacity: 0.028 m³
Lightweight Build: Weighing only 1000kg, the SD12D is easy to transport and maneuver on-site.
Durable Components:
- Boom Length: 1490mm
- Arm Length: 800mm

Applications:

Ideal for utility work, small construction jobs, farm tasks, and DIY excavation projects — the SD12D brings professional-grade performance to compact-scale jobs.

Reviews

There are no reviews yet.

Be the first to review “SD12D 1 Ton mini excavator”

Bucket capacity	0.02m3
Engine Brand	Kubota
Hydraulic Cylinder Brand	Eaton
UNIQUE SELLING POINT	High digging power
Make	SHANDING
Video outgoing-inspection	Provided
Core Components	Engine, Motor
Place of Origin	shandong china
Maximum Digging Height	2450mm
Machine Weight	2700 kg

Moving Type	Crawler Excavator
Hydraulic Pump Brand	SHIMADZU
Hydraulic Valve Brand	NHI
Warranty	1 Year
Machinery Test Report	Provided
Color	Blue, Green, Yellow
Brand Name	SHANDING
Power (W)	7.6km/3000rpm
Maximum Digging Depth	1760mm
Max Digging Radius	1490mm

Engine type	koop
Rated power	7.6kw
Working pressure	16MPa
Length * width * height	27009251550mm
Platform width	920mm
Tail radius	6800mm
Track length	1210mm
Platform clearance	420mm
Dozer sinking/lifting height	230mm/210mm
Maximum excavation height	2650mm
Maximum unloading height	1750mm
Maximum digging depth	1650mm
Maximum excavation radius	2950mm
Minimum radius of turn	1425mm
Maximum climbing capacity	30°
Maximum travel speed	2.1km/h
Main pump flow	25L/Min
Platform turning speed	9-11rpm
Bucket capacity	0.028m³
Ground pressure	18.9N/㎡

Brand	SHANDING
overall weight	1960Kg
bucket capacity	0.06m³
engine power	14.7KW
speed	2200r/min
Pressure of hydraulic system	18MPa
Climbing slope	30°
Grounding pressure	32kpa
walking speed	2.5-4.5Km/h
Max. traction	15KN
Platform turning speed	13rmp
Maximum Digging Force	15KN
engine model	Perkins can choose Yanmar Euro stage V
pump	Futai Three pump system
Rotary motor	EATON
Walking motor	EATON
Max.digging height	3400mm
Max. dump clearance	2160mm
Max.digging depth	2050mm
Max.digging radius	3600mm
Max. horizontal mining distance	2950mm
Rear radius of rotation	1760mm
Max. shovel depth	220mm
Max. elevation of bulldozer	250mm
boom length	1860mm
arm length	940mm
bucket size	480mm
Machine configure	Overall size
overall length	3400mm
overall width	1000-1300mm
overall height	2200mm
Turning radius of platform	1760mm
track length	1650mm
track width	250mm
ground clearance	245mm
Height of moving arm end	1450mm
Platform Width	980mm
engine backcover height	650mm
Platform ground clearance	490mm

Boom length	3300mm
Ammlength	1850mm
Max.digging reach	6400mm
Max.digging depth	4750mm
Max.digging force	45KN
Max.digging height	6830mm
Max.dumping height	5000mm
radius of gyration	2700mm
Shipping size (L * W* H)	590019803100mm
Axle base	2500mm
Wheel base	1450mm
Ground clearance of counterweight	1060mm
Min.ground clearance	≥285mm
